Hey guys
Thought i'd start a thread to help us figure out what fits and what dosent. Please copy and paste template to keep it uniform cheers.
I'll start......
Wheel: Rota slipstreams
Size: 16x7in
Offset: +40
Color: gun metal grey machined lip
Tire:Toyo T1-r
Size: 205/45/16
Lowered?: Yes
If Yes, What Setup?: King springs super lows
Front Rubbing: yes
Rear Rubbing: none
Comments: only rubs when on full lock
Picture:
http://users.bigpond.net.au/z0r-indu...e/pict8929.jpg
Cheers EGJOE:thumbsup:
whether or not your wheels scrub does not depend on the wheel itself, but depends on the specifications of your wheel. ie: width, offset.
other factors include your suspension characteristics ie: camber and height
so in saying that, any EG/EK/DC2 can run 15x7 40-45 wihtout scrubbing no matter how mcuh you lower it
on a lowered eg, on 15x7 or 16x7 what sort of offset could i run without scrubbage, on stock guards?
[QUOTE=zco;1700257]whether or not your wheels scrub does not depend on the wheel itself, but depends on the specifications of your wheel. ie: width, offset.
Which is the wheel itself ??
Hmmm
Does the list i made not include wheel type, wheel size, width, offset, tyre size, suspension setup??? Lets not argue please.:D
Thread is suppose to be a guide. who ever post up has the wheels on their own car, so it must fit but how well is what im asking. Hopefully will give us all an idea of what works and what dosen't.
Wheel:
Size:
Offset:
Color:
Tire:
Size:
Lowered?:
If Yes, What Setup?:
Front Rubbing:
Rear Rubbing:
Comments:
Picture:
You see im just trying to help out people like trism.
Stay tuned Buddy hopefully some people will start contributing.:thumbsup:
Heres a link of what im going on about it for honda jazz though but you get the picture...
http://www.fitfreak.net/forums/fit-s...-included.html
if people can do it, it will be good, coz im sick to shit of having to sift thru thousands of threads trying to find shit
Yeh definitely agree with you trism, Come on guys share and care:)
maybe include ride height if lowered?:thumbsup:
good idea :cool:
Wheel: SSR MKII-R
Size: F 16x7 R 16x8
Offset: +38
Color: Silver Polished Lip
Tire: Toyo Proxes 4
Size: 205/45/16
Lowered?: Y
If Yes, What Setup?: Zeal Function / tucking tyre
Front Rubbing: Y because wrong tyre profile should run 205/40/16
Rear Rubbing:N
Comments:
Picture: http://www.ozhonda.com/forum/showthread.php?t=89880
<----------------
thanks buddy :thumbsup:
This eg h22a car http://i224.photobucket.com/albums/d...DSCF8708-1.jpg
what zco is trying to say is, wheels come in all different brands, shapes, styles and designs. but what's universal is the measurement of size, width and offset of the rims. so instead of listing hundreds of combinations, it's easier to understand these dimensions to estimate whether rims will scrub or not.Quote:
Originally Posted by zco
anyone want a quick lesson? ok for eg's (and most small hondas in general like dc's, ek's) a standard fitting wheel would be about 15" x 7" wide, with offset between +45(mm) and +50(mm). this is stock/oem fitment, so if you go superlow front or back, it should not rub.
to understand offset, if you buy the same rim in 15" x 7" but offset is now
+35 (compared to original of +45), this means the wheel will sit 10mm further out from the hub, or from another perspective, 10mm closer to the guards. this increases chances of scrubbing against the guards if the suspension is low. the lower you go, the more likely it'll scrub the guards and stick out. if the offset is higher at +55, vice versa - will sit 10mm deeper within the wheel arch and closer to the the shocks / suspension arms.
so with width... if you get a 15" x 8" wheel with stock offset of +45, it'll sit 1/2" closer to the guards as well as 1/2" closer to suspension. wheel position doesn't move, but rim width is just wider.
with all this, imo the safest size for 15"-17" wheels is somewhere between 6.5"-8" wide with offset between +32 and +50. also, tyre size also comes into play, but that's another story, lol... as long as tyre size is a reasonable width, it'll fit. i wouldn't go fatter then 205 or 215 for smaller Hondas.
i've tried many combinations on my car... craziest i've gone is 16" x 8.5" offset +26 (with 205/45/16 stretched) at the rears. These not only stuck out of my guards, they didn't even tuck under so it was potentially scrubbing even without going over a bump! lol.
anyway, do your research before buying weird sizes/offsets. :thumbsup: i love wheels! :p
ok so lets say i wanted fitment like this car
http://img156.imageshack.us/img156/9/32lq4.jpg
http://img156.imageshack.us/img156/524/80400516ak1.jpg
what size and offset does that look to be running?
Wheel: desmond rega master
Size: 16x7in
Offset: +45
Color: polished
Tire:yoko c drives
Size: 205/45/16
Lowered?: Yes
If Yes, What Setup?: cusco zero 2
Front Rubbing: no
Rear Rubbing: none
Comments: 5 lug
Picture: none
Wheel: rays te37
Size: 16x7in
Offset: +45
Color: bronze
Tire:advan ad07
Size: 205/45/16
Lowered?: Yes
If Yes, What Setup?: cusco zero 2
Front Rubbing: no
Rear Rubbing: none
Comments: 5 lug
Picture: none
hahaha trism that eg is super dumped.
looks like its running 205/50/16's
i hope you realise that car will handle like absolute shit,scrub the front on turns and bumps and scrub the rears when if ppl get in the back....and your rear tyres will last about 3 months until the inside edge is completely worn out from that bullshit crazy negative camber.
look at the angle of the rear lca's,its ridiculous,you need to understand that the arms were not designed to be run at that angle,every arm in your car will suffer wear and your car will feel like a boat,that constantly scrubs.
but goodluck lol
yeh but but how fat does that car look eh? :thumbsup:
That red civic got stolen and had all its parts stripped.
Wheel: Buddyclub QF
Size: 15 x 7
Offset: +35
Color: Black
Tire: Falken RT615
Size: 205/50/15
Lowered?: Yes
If Yes, What Setup?: Buddyclub Race Spec
Front Rubbing: No
Rear Rubbing: No
Comments: Perfect. Clear the Type-r brake.
Picture:
http://i82.photobucket.com/albums/j2...a/IMG_0212.jpg
yeah thats all true.Quote:
Originally Posted by teh_mechanic
wont be that low, and the camber isnt too worrying, as its a track/touge car.
with no backseats, so no need to worry bout that :P
but yes, i understand thats way too low, i just like the wheel fitment. what sort of offset would you think it would be running? +30s?
yes, yes it does lolQuote:
Originally Posted by lilhaulerz
indeed it did :( sad story that oneQuote:
Originally Posted by Chi
Good to see some positive discussion happening:D
Thanks for contributing guys:thumbsup:
Quote:
Originally Posted by moo moo nel
asif steal my old colour scheme...
http://www.ozhonda.com/gallery/data/521/3116_1612.jpg
[quote=trism;1711902]
wont be that low, and the camber isnt too worrying, as its a track/touge car./quote]
Track cars and especially touge cars need some suspension travel
no, that was aimed at the camber, not the suspension travel :)
Large amounts of negative camber doesn't necessarily mean the car will handle better...
*sigh*
im not worried about massive amounts of camber chewing daily tyres for the reason i stated above.
i didnt say im gonna run massive neg camber, nor did i say that i was expecting it to handle better
Yea, i know what your getting at. It does look wicked.
yes damm good looking:p
this is a good thread idea imo. ill keep it on topic. imo if you want to comment go for it, but at least add your info :thumbsup:
i think there are way too many variables to say without a doubt what will or wont work on an eg.
Wheel: Enkei Racing S
Size: 15 x 6
Offset: +38
Color: Battle ship Grey w/polished lip
Tire: Goodyear Eagle
Size: 195/50R15
Lowered?: Yes
If Yes, What Setup?: Buddyclub Race Spec Damper
Front Rubbing: Onfull lock w/passenger and interior
Rear Rubbing: No
Comments: Very pleased with setup
Picture:
http://www.tunerzine.com/articles/275/images/2.jpg
[quote=EGJOE;1700825]the wheel itself - by that i mean, the brand of wheel. ie: rota slip streamQuote:
Originally Posted by zco
the difference between which wheel fits and which doesnt all lies in the offset, camber height and tyre size you run
so if you read up on those, then you would know which wheels fit and which dont. you can fit any wheel you want if your car was raised
hard to tell what size... look like 15s to me...Quote:
Originally Posted by trism
my guess would be 15x7 +24... cos +32 generally would sit flush with the guards without camber. This guy's camber is nuts, so the offset's gotta be lower imo...
The tyres ain't stretched (can tell as rim dish ain't sticking out past tyre wall) so he's got some stockish width, i reckon 195/50/15 cos it's pretty low profile.
But yeah, have fun driving like that :thumbdwn:
Thats looking good buddy!!! As borat would say 'Very Nice' :thumbsup: Thanks for adding to the thread, hope more will followQuote:
Originally Posted by egSi
CHEERS
EGJOE
work emotions 17s
stock height:zip:
soon to be kings super lows
205/40r17
scrapes with passengers! I HATE IT lol
most of my mates have egs with 17s and kings and they dont scrape?? maybe owm spring too soft?
Cool Vti i looked for one for ages not many good examples left out there:thumbsup:
Thanks for adding to the thread:cool:
EGJOE
How does the good year eagle handle?Quote:
Originally Posted by egSi
from his pic they look like gsd-03(big diff to standard eagle f1) stickiest rubber i've ever used managed to tame my old rb powered silvia:thumbsup:
JOE
No. That eg is running 15x7 +35 offset with 195/50/15. Should rub over humps even with max rolled guards.Quote:
Originally Posted by EK9
Mine
Wheel: Enkei Racing S
Size: 15 x 6.5
Offset: +32
Color: black w/polished lip
Tire: bridgestone gIII and proxes 4
Size: 205/50R15
Lowered?: Yes
If Yes, What Setup?: apexi type v damper
Front Rubbing: Onfull
Rear Rubbing: Yes, because of wide tyres and guard not rolled.
Comments: With a setup like this u must camber or get smaller tyres to cancel the rubbing. otherwise dont bother with passengers and back seats.
Will update again when roll 15X7 +25 offset and 15x7 +45 offset.
thats alright,coz the only thing in the back will be a halfcage.
with a bit of camber, you reckon 15x7 with +25 on front, +30ish on back would be sweet?
with 205/50/15s?
Thanks sir vtec for adding to the thread :thumbsup:
Hoping to see some tyre tucking on sunday:cool:
EGJOE
http://i306.photobucket.com/albums/n...e/DSC04248.jpg
Another pic :thumbsup:
That's Phaze2 EG's (search honda-tech.com). I'm unsure about the above polished CP-R's, but this is the same car running 15x8 +10 Equips 03's.Quote:
Originally Posted by trism
Looks hot though, but I don't know about actually driving it.
http://img220.imageshack.us/img220/6...8ti7pr0wz1.jpg
http://img207.imageshack.us/img207/7294/215pm1.jpg
http://img210.imageshack.us/img210/518/131ec3.jpg
all these balling cars are for show.Quote:
Originally Posted by shebangs
they drive it to photoshoots and big meet ups. all the other times, they sit in the garage
yup But dam they are hot.
are you sure about this? i highly doubt it... look at the dish and amount of camber he has. with the size/offset u mentioned, you wouldn't even need to camber that much.Quote:
Originally Posted by Sir_vtec
i've run at 16x8 +28 on my EK at the rears, and with some camber like him, it would have looked very similar...
damn... so like i mentioned earlier, it's reasonable to guestimate the first set at around +2x...Quote:
Originally Posted by shebangs
Wheel: Dc5r stockies
Size: 16x7in
Offset: +45
Color: Alloy
Tire:Kumho Ecsta
Size: 205/45/16
Lowered?: Yes
If Yes, What Setup?: Tanabe Coilovers
Front Rubbing: Nope
Rear Rubbing: Nope
Comments: 5 stud and Type r Brakes. Brake calipers are about 1-2mm from touching the rim on the front.
Picture:
http://www.forghani.net/forum/files/...large__208.jpg
5 llug ftw!!!
thanks bro for adding :thumbsup:
man they almost look like 17'
EGJOE
lol thats coz they are almost 17"
hey guys
quick question maybe one of you guys can answer. what size rims and offset are standard on an eg6 sir hatch?
15x5.5 195/55/15 tyres
come on guys add to the thread
Oh Travis, you still around mate?
Nice ride as always. Loved your rocker cover and insane ride height. :)
new year bump for the newbies
